Overall Length(mm) | 6570 | Engine Model | YC4FA115-40 |
Overall Width(mm) | 2250 | Emission Standard | Euro-IV |
Overall Height(mm) | 2780 | Wheel Base(mm) | 3300 |
Interior Height(mm) | 1860 | Position/Fuel | Front/Diesel |
F/R Overhang(mm) | 1160/2110 | Max. Power(kw) | 85 |
Departure/Approach | 22/14 | Max. Torque(N.m) | 300 |
First Step Height(mm) | 400 | Emission | 2982 |
Max. Manufacturer’s Total Mass(kg) | 6500 | Rated Passengers Capacity(person) | 1932/10/24 |
Chassis Model | EQ6570K4AC1 | | |
Clutch | Single,Dry,Diaphragm Spring,Clutch booster | | |
Front Axle | Dongfeng Dana Axle(2.3T) | | |
Rear Axle | Dongfeng Dana Axle(5T) | | |
Suspension | Steel plate spring, Front:8/ Rear:10 | | |
Steering | Mechanical | | |
Brake | Double circuit pneumatic braking,Central drum brakes | | |
Fuel Tank | 90L | | |
Tire | 7.00R16-12PR | | |
Battery/Generator | 6-QA-105/55A,70A | | |
Others | Engine pre-heating device,Aluminum tank,ABS,Adjustable arm,Clutch booster,Dryer, | | |
Body Structure | Semi-integral Body | | |
Interior Trimming | Common Trimming | | |
Doors | Middle & Rear pneumatic folding doors | | |
Side Windows | Fastened type for upper, push-pull type for below, light green color | | |
Windshield | Front: laminated glass with defroster & wiper; Rear: toughened glass | | |
Rearview System | Manual steel-rack type rearview mirror; Inner mirror | | |
Heating System | Common heater, 130 W, 2 air outlet, 25mm for water heating pipe | | |
Defrost System | 24V, 180W, 2-gear, 25mm for water heating pipe | | |
Audio-Visual System | N/A | | |
Lamps | Front/Rear combination lamps | | |
Wiper | Opposite-type electric wiper | | |
Hatch Door | Horizontal side door for air filter, Steel stamping hatch, Luggage room in left sides. | | |
Seats | 2+1 layout,23 seats,City seats with cushion, seat width: 400 mm | | |
Paint | Domestic paint | | |
Others | PVC floor,Flat floor,Fan,Safety hammer,120 A Camel brand storage battery,700A skylight,Knurling handrail with hand rings,passenger | | |
| door emergency air escape cock,Air horn | | |
