Dimensions | | | Photo | |
Overall Length | | 7005 mm | | |
Overall Width | | 2050 mm | | |
Overall Height | | 2640 ,2760 mm | | |
Interior Height | | 1820 mm | | |
Wheelbase | | 3935 mm | | |
Front Overhang | | 1150 mm | | |
Rear Overhang | | 1920 mm | | |
First Step Height | | 400 mm | | |
Gross Vehicle Weight | | 5900 kg | | |
Seats Capacity | 10-26 | | | |
Rear Luggage Compartment Volume* | | 0.25 m3 | | |
Engine | | | | |
Engine Model | YC4FA130-30 | | | |
Engine Type | in-line,water-cooled, 4 cylinders, | | | |
| turbocharged, electronic control, direct injection | | Safety & Performance | |
Position/Fuel | Front/diesel | | Standard | |
Max Output | 95 kw | | ABS (Antilock Braking System) | |
Max Torque | 340Nm/rpm | | GPS System, vehicle travelling data recorder | |
Displacement | 2982mL | | Speed-limiting device (100km/h top ) | |
Emission Standard | national standard III | | Safety belt equipped with every seat | |
Chassis | | | Heating system | water heating (3 radiator) |
Chassis Model | EQ6680KS3T | | Dongfeng Pannico top-mounted A/C 12KW(10500cal/h) | |
Gear box | DF5S410 | | Antiskid floor, digital clock | |
Clutch | Single plate, dry friction, diaphragm spring /Φ325mm | | Interior rearview mirror, sun visor for the driver | |
Front Axle | Jiang Lin (2.25T) Disc brake | | Side window curtain, rear window curtain, tyres decorate cover | |
Rear Axles | Jiang Lin (4T), i=4.875 | | 4 safety hammer, 2kg Fire Extinguisher | |
Suspension | Leaf spring front 3 rear 4 | | Optional | |
Steering | Power steering | | Nan Feng fuel heater YJ-Q11.6R | |
Brakes | Dual circuit liquid brake | | LG antiskid floor, 4kg Fire Extinguisher | |
Fuel Tank | 300L | | 7-inch color screen reversing rearview monitoring system | |
Tyres | 7.00R16 | | Entertainment Systems & Digital Amenities | |
Parking Brake | central drum regulation brake | | Standard | |
Battery/Generator | 6-QA-180, 12V/150A | | MP3 radio system | |
Others | Adjustment arm; ABS; air dryer; copper water tank; | | Digital clock | |
| engine intake air preheater | | Adjustable armrest, 2+1 layout | |
Body | | | Driver door, middle electric folding door | |
Body Type | Stainless steel frame, | | New front and rear combination lamp | |
| punch forming of front mold and rear mold | | Front/rear fog lamp, side steering lamp, high mount stop lamp | |
Interior Trimming | Coaster luxurious interior trimming; | | Optional | |
| | | MP4/MP5 video system | |
Side Window | Fully sealed, integrated splice windows in green color; | | 15-inch color LCD | |
windscreen | Front : laminated glass; Rear : toughened glass | | U flash disc, SD card | |
Defroster | Defroster with changeable power 24V,130W | | Folding side window curtains,rolling sunshade curtains | |
Windscreen Wiper | Front: double arms type; Rear: single arm type | | Monitoring system | |
